Version: 13. Sepe,mer 2004
30
Section 9 RX/TX Mixer, Low pass filter
The following transistors may easy be damaged by ESD. Dont
forget to discharge yourself, use a potential free soldering
station.
The three leads of the BFR96 should be bent carefully down, the writing
should be readable, when the transistor is in place.
[ ] T9 BFR96(S) E4
[ ] T10 BFR96(S) D5
[ ] T11 BF244A C/D5
For the mixer TUF 1 you have to be careful about short to the pc
board as with crystals. Mount it with the help of two pieces of cut
off resistor leads as help, and remember to remove them after
soldering! Remember to mount the mixer in proper direction. See-
ing it from below, note that the leads aren’t centred. At the component
side, you can see how to orient it. (Shown as the mixer as a transparent
object in the drawing).
[ ]M1 Mixer TUF1 D3/4
Now a few diodes, check their value with a loupe, not to mix
them up.
[ ] D4 BA479 E/F3
[ ] D5 BA479 E3
[ ] D6 BA479 D3/4
[ ] D7 BA479 D4
[ ] D8 BA479 D/E4
Now the other type
[ ] D9 1N4148 F2/3
[ ] D10 1N4148 F2/3
[ ] D11 1N4148 F2
[ ] D12 1N4148 F2
SMCC RFCs are well known by now
[ ] Dr1 10µH SMCC F3
[ ] Dr2 47µH SMCC E3
[ ] Dr3 47µH SMCC D/E 3/4
[ ] Dr4 47µH SMCC E3/4
[ ] Dr5 10µH SMCC C/D 4/5
[ ] Dr9 10µH SMCC F3
and now a lot of caps.
[ ] C35 47nF 473 E4
[ ] C36 47nF 473 E4
[ ] C37 100nF 104 E3/4
[ ] C38 47nF 473 E4
[ ] C39 47nF 473 E3/4
[ ] C40 47nF 473 F2/3
[ ] C41 47nF 473 F3/4
[ ] C42 47nF 473 E3
[ ] C43 47nF 473 D3
[ ] C44 47nF 473 D3
[ ] C45 47nF 473 E3
[ ] C46 47nF 473 D4
[ ] C47 100nF 104 D5
[ ] C48 47nF 473 D5
[ ] C49 47nF 473 D/E5
[ ] C50 15pF 15p D5
[ ] C51 47nF 473 C5
[ ] C52 10nF 103 C5
[ ] C73 150pF 151,n15 G2
[ ] C74 120pF 121;n12 G1/2
[ ] C75 120pF 121;n12 G1
[ ] C76 120pF 121;n12 G1
[ ] C77 120pF 121;n12 G1
[ ] C78 150pF 151;n15 H1
