QTech QSR-2920 Series User Manual

Installation Manual
1. Router Introduction 15
www.qtech.ru
Figure 1-7 The front appearance diagram of QSR-2920-14-AC-AC
1. Reset button
2. Function status indicator
3. USB CONSOLE port
4. RJ45 CONSOLE port
5. USB interface
6.1000Base-x SFP Ethernet COMBO
optical interface
7.1000Base-T Ethernet COMBO
electrical interface
8. GE port (GE0/0– GE0/23)
9. Fan outlet
Figure 1-8 The rear appearance diagram of QSR-2920-14-AC-AC
1. Grounding screw
2. Power 1 switch
3. Power 1 socket
4. Power 2 socket
5. Power 2 switch
6.Slots of MX9 interface sub card (S1-
S4)
1.5. QSR-2920-14P-AC Appearance and Hardware
The dimension of QSR-2920-14P-AC is 442mm × 380mm × 44.2mm (W x D x H). The front
appearance diagram of QSR-2920-14P-AC is shown in Figure 1-9, and the rear appearance
diagram is shown Figure 1-10.
