3. ROUTER INSTALLATION
3.1. Install Router
Based on different installation positions, the router can be installed in the following two
modes:
 Install the router to the workbench.
 Install the router to the cabinet.
1.3.1. Install Router to Workbench
Place the router on the clean workbench. Pay attention to the following operation during the
installation:
 Ensure the stability and well-grounding of the workbench.
 There is 10cm heat dissipation space around the router.
 Do not place heavy things on the router.
2.3.1. Install Router to Cabinet
This section describes how to install the QSR-2920 series router to the 19-inch standard
cabinet.
Installation Preparations
 QSR-2920 series router is 1U high, so ensure that enough installation space is reserved for
the router.
 Check the grounding and stability of the cabinet and ensure that there is no obstacle inside
and around the cabinet affecting the router installation.
 1U is 44.45mm. Here, U is short for Rack Unit.
Install Slide to Cabinet
The slide supports the router weight. If a slide is already on the cabinet, skip this section.
 Besides the slide, a tray also can be used to support the router. The
installation process of the slide is the same as that of the tray. Therefore,
the tray installation process is omitted in this installation manual.
