Connection cable
Single mode fiber or multimode fiber
3.7.2. USB Interface Attributes
Appendix Table 7.3.1.1-1 USB interface attributes
Attribute
Description
Interface standard
USB2.0
Interface type
USB Type-A
Work mode
1.5Mbps, 12Mbps, 480Mbps Host
(it can be pulled out after un-installing
the USB device via the command)
Cables
no
4.7.2. CONSOLE Port Attributes
Appendix Table 7.3.1.1-1 CONSOLE Port attributes
Attribute
Description
Interface standards
Asynchronous EIA/TIA-232
Connector type
RJ45
Baud Rate
2400bps/4800/9600/19200/38400/115200bps
Default value: 9600bps
Supported services
Connect the local terminal (such as PC) and
run the terminal emulation program on the
terminal.
5.7.2. Micro USB Interface Attributes
Appendix Table 7.3.1.1-1 Micro USB interface attributes
Attribute
Description
Interface standard
USB2.0
Interface type
Micro usb
