Getting Started | 11
No. Item Function
1 MiniSD Card Slot Lets you insert a storage card (miniSD) for storing data.
2 POWER Button Press to turn off your device temporarily and switches
the device to sleep mode; press and hold (about five
seconds) to turn off your device completely.
When your device is in sleep mode, you can still use
the phone function to receive calls; however, the phone
function is off when you turn off the device completely.
3 Notification LED 1 Bi-color LED on the left side: Blue for Bluetooth system
notification of powered-up and ready to transmit radio
frequency signal, and Green for Wi-Fi status.
4 Speaker Listen to audio media or a phone call from here.
5 Notification LED 2 Bi-color LED on the right side: Green and Amber for
GSM standby, SMS message, GSM network status,
notification, battery charging status.
6 Internet Explorer Press to launch Internet Explorer.
7 Messaging Press to quick start your Messaging.
8 Touch Screen Use to write, draw, or make a selection with the stylus.
9 Left SOFT KEY Performs the command shown in the label above the
button.
10 Right SOFT KEY Performs the command shown in the label above the
button.
11 END Button Press to end a call.
12 Navigation Pad Press this multi-directional control up, down, left, or right
to move through menus, program instructions; carry out
the selection by pressing the center button.
13 TALK Button Press to answer an incoming call or dial a number.
14 Volume Controller Press up or down to adjust the volume.
15 Comm Manager Press to start Comm manager; press and hold to switch
to vibration mode.
