August 13, 2018 7036-187M 45
MT. VERNON AE INSERT
Service Parts
R
MT VERNON INSERT-AE
Beginning Manufacturing Date: Sept. 2006
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and
Home Technologies does not sell directly to consumers. Provide model number and serial number when
requesting service parts from your dealer or distributor.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
Adaptor, TPVNT-4
Bracket, Control Board 7034-212
Bracket, Door Switch 7034-215
Bracket, Hopper Switch 7082-148
Bracket, Snap Disc 7034-150
Bracket, Vacuum Switch 7034-211
Component Pack:
Matte Black SRV7036-018
Sienna Bronze SRV7036-019
No longer available
7036-020
Mahogany SRV7036-021
Cleanout Tool 414-1140 Y
Paint Touch-Up
Pre #HF1910001 812-0910
Post #HF1910001 3-42-19905
Sienna Bronze TOUCHUP-CSB
No longer available
TOUCHUP-CWL
Mahogany 855-1450
Power Cord 812-1180 Y
Thermostat Wire 3 Cond SRV7000-409 Y
Wall Control SRV7000-549 Y
Face Plate 7034-124
Fuel Level Sensor SRV7000-523 Y
Gasket, Exhaust SRV7034-109
Gasket, Extruded - Field Cut to Size 10 Ft 7000-320/10
Gasket, Extruded Edge - Field Cut to Size 10 Ft 7000-319/10
Heating Element Assembly 18” (Loop Igniter), 380 Watt
SRV7000-462 Y
Pkg of 10 SRV7000-462/10 Y
Heating Element Assembly 18”, 120 VAC, 300 Watt, (Wood
Pellet Fuel Only)
SRV7000-647 Y
Pkg of 10 SRV7000-647/10 Y
Washer, 1/4 Sae Pkg of 24 28758/24 Y
Wing Thumb Screw 8-32 X 1/2 Pkg of 24 7000-223/24 Y
Hinge Pin, Gold Pkg of 2 844-5750 Y
Paint, 12 oz Can
Sienna Bronze /
Espresso
PAINT1-CSB/CES
Willow / Tuscan Olive
PAINT1-CWL/CTO
Thermocouple K. Ring Mount Drop Tube SRV7000-381 Y
Additional service part numbers appear on following page.
