PARTS LIST
DESCRIPTION ENG.QTYITEM
FRAME WITH UNIVERSAL ATTACHMENT KIT
IMPORTANT: Most elements of the frame are preassembled.
Before making the final assembly, check condition of the parts
and that the nuts and bolts are tight.
B
C
DA
F
E
Hook mount & hitch ball assembly
1A
Front mounting tube & rotation plate assembly
1
B
Push chanel1C
Rear impact frame & hook assembly1D
Springs
2E
Chains stabilizer & bracket assembly
1
F
with chains
C
ARTON CONTENTS
