QUADRAX Q-LOCK - Default Chapter; Table of Contents

TABLE OF CONTENTS
1
PRODUCT DESCRIPTION……………………………….
p2
IMPORTANT NOTICE BEFORE INSTALLATION………
p3
DIMENSIONS TABLE…………………………………….
p4
INTRODUCTION………………………………….………..
p6
SAFETY PRECAUTIONS………………………………….
p8
LIMITED WARRANTY……………………………………..
p10
CARTON CONTENTS…………………………………….
p11
..ASSEMBLY
I
n
s
talling the hook mount assembly………………………. p12 step 1 & 2
Measure to determine the position of the blade…………. p13 step 3
Installation of the front mounting tube and rotation plate.. p13 step 4
Installation of the push chanel and rear frame……………p14 step 5
Installation of the chains stabilizer anchor brackets…….. p14 step 6
Secure the plow blade assembly to the ATV…………….. p15 step 7 & 8
Installation of the chains stabilizer………………………… p16 step 9 & 10
Installing pulley…………………………………………….. p17 step 11
Installing pulley (continued)……………………………….. p18 step 11
OPERATION
To turn the plow……………………………………………. p18
Use the front receiver pin…………………………………. p19
Verifying the proper operation of the assembly…………. p19
MAINTENANCE
Replacing the safety bolt……………………………………p20
Greasing the moving parts………………………………… p20
Rotation plate………………………………………………..p21
Articulated arm ……………………………………………..p22
Chains stabilizer and bracket………………………………p23
Push channel………………………………………………. p24
Impact frame, coupling hook and mount………………….p25 & 26
Pulley assembly……………………………………………. p27
ACCESSORIES SOLD SEPARATELY
Cable remote control kit…………………………………….p28
2" Receiver hitch and application list………………………p29 & 30
Frame extension kit…………………………………………p31
TORQUE SPECIFICATION TABLE………………………
p32
PARTS BREAKDOWN
