Chapter 1
15
QBOX-1010 User’s Manual
System tour
Refer to the diagrams below to identify the components of the system.
Front Panel
Figure 1 Front Panel
eSATA
The eSATA connector provides an external connectivity for mass storage
devices.
CAUTION
This connector do not support hot-swapping. Users should not connect or
disconnect their eSATA devices from PC when the system is working.
USB
The USB (Universal Serial Bus) port is compatible with USB devices such as
keyboards, mouse devices, cameras, and hard disk drives. USB allows many
devices to run simultaneously on a single computer, with some peripheral acting as
additional plug-in sites or hubs.
