Quanmax QBOX-1010 User Manual

Chapter 3
28
QBOX-1010 User’s Manual
Table 6 OnBoard I/O Configuration Settings
BIOS SETUP UTILITY
Main Advanced Boot Chipset Power Security Exit
OnBoard I/O Configuration
COM1 Address [3F8/IRQ4]
COM1 Function Type [RS232]
COM1 RI PIN Voltage [Normal]
COM2 Address [2F8/IRQ3]
COM2 Function Type [RS232]
COM2 RI Pin Voltage [Normal]
Allows BIOS to Select Serial
Port1 Base Address.
<> Select Screen
↑↓ Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
V02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
COM1 Address [3F8/IRQ4]
Options: Disabled, 3F8/IRQ4, 3E8/IRQ4, 2E8/IRQ3
COM1 Function Type [RS232]
Options: RS232, RS422, RS485
COM1 RI PIN Voltage [Normal]
Options: Normal, 5V, 12V
COM2 Address [2F8/IRQ3]
Options: Disabled, 2F8/IRQ3, 3E8/IRQ4, 2E8/IRQ3
COM2 Function Type [RS232]
Options: RS232, RS422, RS485
COM2 RI Pin Voltage [Normal]
Options: Normal, 5V, 12V
Table 7 OnBoard Peripherals Configuration Settings
BIOS SETUP UTILITY
Main Advanced Boot Chipset Power Security Exit
OnBoard Peripherals Configuration Settings
USB Controller [Enabled]
USB 2.0 Controller [Enabled]
Audio Controller [Enabled]
Onboard LAN Controller [Enabled]
Onboard LAN OPTROM [Disabled]
Options
Disabled
Enabled
<> Select Screen
↑↓ Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
V02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
USB Controller [Enabled]
Options: Enabled, Disabled
USB 2.0 Controller [Enabled]
Options: Enabled, Disabled
