Quanmax QBOX-1010 User Manual

Chapter 3
26
QBOX-1010 User’s Manual
 Main Menu
The BIOS Setup is accessed by pressing the DEL key after the Power-On Self-Test
(POST) memory test begins and before the operating system boot begins. Once you
enter the BIOS Setup Utility, the Main Menu will appear on the screen. The Main
Menu provides System Overview information and allows you to set the System Time
and Date. Use the “<” and “>” cursor keys to navigate between menu screens.
Table 2 BIOS Main Menu
BIOS SETUP UTILITY
Main Advanced Boot Chipset Power Security Exit
System Date [Wed 07/03/2009]
System Time [10:18:15]
> Primary IDE Master :[Not Detected]
> Primary IDE Slave :[Not Detected]
> Secondary IDE Master :[Not Detected]
> System Information
Use [ENTER], [TAB]
or [SHIFT-TAB] to
select a field.
Use [+] or [-] to
configure system Time.
<> Select Screen
↑↓ Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
V02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
Below table is described for Primary IDE Master, Primary IDE Slave, Secondary IDE
Master setting.
Table 3 IDE Device Setting Menu
BIOS SETUP UTILITY
Main Advanced Boot Chipset Power Security Exit
Primary Master
Device :Not Detected
LBA/ Large Mode [Auto]
DMA Mode [Auto]
S.M.A.R.T [Auto]
Disable: Disables LBA Mode.
Auto: Enables LBA Mode if the
device supports it and the
device is not already formatted
with LBA Mode disabled.
<> Select Screen
↑↓ Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
V02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
LBA/ Large Mode [Auto]
Enables or disables the LBA (Logical Block Addressing)/ Large mode. Setting to
Auto enables the LBA mode if the device supports this mode, and if the device was
