12 Installing the DXi6701 or DXi6702 System
DXi6701/DXi6702 Installation and Configuration Guide
Figure 5 Removing the
Internal Chassis Rail (Right-
hand Shown)
2 Install the internal chassis rails on the chassis tabs (see Figure 6):
a Slide the internal chassis rail toward the front of the chassis to engage the
chassis tabs.
b Secure with a single Phillips screw on each side of the node chassis.
Quick release latch
Rack mounting rail (expanded)
Internal chassis rail
To Next Page
