Quantum DXi6701 User Manual

14 Installing the DXi6701 or DXi6702 System
DXi6701/DXi6702 Installation and Configuration Guide
Figure 7 Installing the Rack
Mounting Rails
Rack mounting rails
Rack mounting rail tabs
R
a
c
k
f
r
o
n
t
Rack rail hole pattern (square holes)
Adapter bracket
Phillips screws
Rack rail hole pattern
(round holes)
Rack mounting
rail tabs
1U
1U
1U
Slide release latch
