Chapter 2 Installation and Quick Start
Installing an Internal LTO-2 Half-Height Tape Drive
10 LTO-2 Half-Height Tape Drive User’s Guide
Table 1 SCSI IDs and
Jumper Settings for
LTO-2 Half-Height in
Drive
Terminator Power 2
By default, terminator power is disabled on the internal LTO-2
Half-Height Tape Drive. To enable terminator power, place a jumper
across pins 11 and 12.
SCSI ID
Jumpers
1–2 3–4 5–6 7–8
0 Open Open Open Open
1 Shunted Open Open Open
2 Open Shunted Open Open
3 Shunted Shunted Open Open
4 Open Open Shunted Open
5 Shunted Open Shunted Open
6 (default) Open Shunted Shunted Open
7 Shunted Shunted Shunted Open
8 Open Open Open Shunted
9 Shunted Open Open Shunted
10 Open Shunted Open Shunted
11 Shunted Shunted Open Shunted
12 Open Open Shunted Shunted
13 Shunted Open Shunted Shunted
14 Open Shunted Shunted Shunted
15 Shunted Shunted Shunted Shunted
Note: The internal LTO-2 Half-Height Tape Drive does not provide
SCSI termination. Thus, a terminator must be installed on the
drive if it is the last device in a SCSI chain.
