Page #52 background imageLoading...
Page #52 background image
Chapter 5 Specifications
Power Specifications
38 LTO-2 Half-Height Tape Drive User’s Guide
Power Specifications 5
The desktop LTO-2 Half-Height Tape Drive comes with a built-in 90-
260VAC (47-63 Hz) automatic switching power supply.
Maximum voltage and power specifications for the internal LTO-2
Half-Height Tape Drive are listed in table 5
and table 6.
Table 5 Voltage and
Current
Table 6 Power
Dissipation
Specification +12 VDC + 5VDC
DC Voltage Tolerance
(1)
12.00 + or – 10% 5.00 + or – 5%
Non-operating max voltage 14 Volts peak 7 Volts peak
Idle current
(1)
0.13 amps RMS 1.4 amps RMS
Standby current (max)
(2)
0.45 amps RMS 1.4 amps RMS*
Typical operating current
(3)
0.71 amps RMS 2.9 amps RMS
Max operating current
(4)
0.83 amps RMS 3.0 amps max RMS
Max. Peak operating
current
(5)
2.34 amps
(1 sec max)
3.0 amps max RMS
Ripple (peak-to-peak) <
100 mV < 100 mV
* RMS parameters measured at the power connector using a true RMS
digital meter.
Specification LTO-2
Idle Power
(1)
9 watts RMS
Standby Power
(2)
12.5 watts RMS*
Typical Operating Power
(3)
23 watts RMS
