Chapter 2 Installation and Quick Start
Installing an Internal LTO-2 Half-Height Tape Drive
LTO-2 Half-Height Tape Drive User’s Guide 15
Table 2 Serial
Interface Connector
Pin Assignments
Connecting a Power
Cable
2
Attach a four-pin power cable to the power connector on the back of the
drive. Figure 5
shows the location of the power connector.
The recommended 4-pin power connector for internal drives is an AMP
1-48024-0 housing with AMP 60617-1 pins or equivalent.
Installing the LTO
Driver
2
If you intend to use your drive with the Microsoft native backup applet
on Windows Server 2003, Windows XP, or Microsoft Windows 2000
operating system, install the appropriate LTO driver. See the Resource
CD. This driver is not necessary with commercial backup application
software.
Registering Your
Tape Drive
2
After you install the internal tape drive, be sure to register it. Registering
your drive ensures that you will receive the latest information about your
drive, as well as other product, service, and support information. For
your convenience, you can register your drive through our Web site at:
www.quantum.com/registration
.
Pin Numbers Description
1+Tx
a
-Rx
d
2-Tx
a
-Rx
d
3Ground
4-Tx
a
-Rx
a
5+Tx
d
-Rx
a
6Sense
d
7Sense
a
8 Reset
a
9Signal
aux
10 Reserved
