Oscillator-Section
<WAVE1>, <WAVE2>, <WAVE3> - WAVE FORM SELECTION
With these controls the waveforms of the oscillators are selected.
<TUNE> - TUNING
With these controls the pitch of the oscillators is adjusted. <TUNE> controls the basic pitch of all
oscillators into octave lengths with oscillator 1 being the reference, while oscillator 2 and 3 can be
de-tuned independently from each other up to 2 octaves from each other against oscillator 1
<ENV-MOD> PITCH – ENVELOPE - SENSITIVITY
With this control the pitch of the three oscillators can be modulated by an envelope.
When the control is in the middle position there is no sound change, turning to left creates a droop
in pitch and to the right a rise in pitch. (The envelope is found in the edit–osc–menu.)
If the [SYNC] is activated the pitch envelope effects only an auxiliary oscillator, which is synced
with oscillator 1.
[SYNC] - OSCILLATOR-SYNCHRONIZATION
This button starts the oscillator synchronization operation of oscillator 1. It will be synchronized
with an additional auxiliary oscillator. The pitch of the auxiliary oscillator is controlled with
<WAVE-1> when this Sync operation is active. This has the advantage that in Sync operation the
basic sound is controlled with <WAVE-1>. In addition the oscillators 2 and 3 are still independent
from the sync operation and are at your disposal.
<LEVEL1-3> - LEVELS 1-3
These controls set the volume of each oscillator independently from one another. When <LEVEL
3> is turned completely to the left, the 3rd oscillator is turned off and the POLYMORPH's
polyphony is doubled from 8 to 16 voices.
RESONANCE-FILTERS - RESONANCE CAPABLE FILTERS
Filter-Section
15
Basics
