POLYMORPH System-Exclusive Format
Request Data from device
Byte Value Remarks
00 F0 System Exclusive start command
01 3F QUASIMIDI id number
02 dv device number = system channel-1
03 26 POLYMORPH id number
04 52 (R)equest data
05 ah adress high
06 am adress mid
07 al adress low
08 dh data count high (2 bit)
09 dm data count mid (7 bit)
10 dl data count low (7 bit)
11 F7 end of System Exclusive
Dump Data to device
Byte Value Remarks
00 F0 System Exclusive start command
01 3F QUASIMIDI id number
02 dv device number = system channel-1
03 26 POLYMORPH id number
04 44 (D)ump data
05 ah adress high
06 am adress mid
07 al adress low
08... dt data (7 bit)
xx F7 end of System Exclusive
Adress Map
Adress Memory section
00 00 00 system parameter
01 00 00 temporary common parameter
01 01 00 temporary sound/mix parameter (part 1)
01 02 00 -"- (part 2)
01 03 00 -"- (part 3)
01 04 00 -"- (part 4)
01 05 00 temporary sequence parameter (part 1)
01 06 00 -"- (part 2)
01 07 00 -"- (part 3)
01 08 00 -"- (part 4)
01 09 00 reserved
...
01 7F 00 -"-
02 00 00 user sound 1
...
02 7F 00 -"- 128
03 00 00 sequence 1
...
03 31 00 -"- 50
03 32 00 reserved
...
03 7F 00 -"-
04 00 00 setup 1 common parameter
04 01 00 -"- part 1 sound -"-
04 02 00 -"- part 2 sound -"-
04 03 00 -"- part 3 sound -"-
04 04 00 -"- part 4 sound -"-
04 05 00 -"- part 1 sequence
04 06 00 -"- part 2 sequence
04 07 00 -"- part 3 sequence
58
