GV50(P) User Manual
TRACGV50UM001 - 10 -
Figure 5. GV50(P) Micro USB Connector
2.4 GV50(P) Extension Cable Color
Table 6. GV50 2-Pin Extension Cable Color Definition
Pin No
Definition
Color
Cable
1
VIN
red
2
GND
black
Table 7. GV50P 4-Pin Extension Cable Color Definition
Pin No
Definition
Color
Cable
1
VIN
red
2
GND
black
3
OUTPUT
brown
