Queclink GV50 - 2.2 Parts List; 2.3 Interface Definition; 2.3.1 GV50 External Interface

GV50(P) User Manual
TRACGV50UM001 - 8 -
2.2 Parts List
Table 2. GV50 Parts List
Name
GV50 Locator
User Cable
Table3. GV50 P Parts List
Name
GV50 P Locator
User Cable
2.3 Interface Definition
2.3.1 GV50 External Interface
GV50 has a 2 PIN cable. The pin definition of the 2-Pin cable is shown below.
