GV55NUsermanual
TRACGV55NUM001 9‐
Table 3. Part List
Name Picture
GV55N Locator 63mm*50mm*21.8mm
User Cable
DATA_CABLE_M (Optional)
The GV55N has a 6 PIN interface connector. It contains the connections for power, I/O.
The sequence and definition of the 6PIN connector are shown in following figure:
Figure 2. The 6 PIN connector on the GV55N
2.2. PartsList
2.3. InterfaceDefinition
