Queclink GV600MG User Manual

GV600MG User Manual
QSZTRACGV600UM0106 5
2.4. GV600MG Standard Cable Color
Table 6. GV600MG Standard Cable Color Definition
Definition
Color
Pin No.
Connector
Pin No.
Color
Definition
PWR1
Red
1
2
Red/Green
RWR2
AGNG
Black
3
4
Black
AGNG
IGN
White
5
6
Green
ADIN1
OUT-3V3
Red/White
7
8
Black/White
GND
1-WIRE
Gray
9
10
NC
NC
OUT/IN1
Blue
11
12
Yellow
OUT/IN2
OUT/IN3
Brown
13
14
Orange
OUT/IN4
EX_RX
Purple
15
16
Purple/White
EX_TX
RXD
Pink
17
18
White/Black
TXD
Note:
The main color of the dual color cable is the first color, for example, Black/White means black is
the main color, and white is the secondary color.
