GV600MG User Manual
QSZTRACGV600UM0106 6
3. Getting Started
3.1. Open and Close the Case
Figure 2. Open the Case
To open: Use a cross screwdriver to loosen the four screws and then lift the top case gently.
To close: Align the top case with the bottom case and then tighten the four screws.
Note:
Pay attention to the following details to close the case. Otherwise, the waterproof capability of
the device may be deteriorated.
1. The positioning poles (total 11) on the top cover must be inserted into the holes of the
rubber ring as shown below.
2. Tighten the screws sufficiently until the rubber ring is squeezed out as shown in the
following figure 1.
