2 Product Overview
AF20 is an automotive grade Wi-Fi and Bluetooth module with low power consumption. It is a single-die
wireless local area network (WLAN) and Bluetooth combo solution supporting IEEE 802.11 a/b/g/n/ac
Wi-Fi standards and Bluetooth 5.0 standard, which enables seamless integration of Wi-Fi and Bluetooth
Low Energy technologies. And it has DFS function and supports both Master and Slave scenarios.
AF20 supports a low-power SDIO 3.0 interface for WLAN, and UART and PCM interfaces for Bluetooth,
and also supports LTE/Wi-Fi & Bluetooth coexistence interface. It is designed to be used in conjunction
with Quectel automotive grade LTE module AG35 so as to provide AG35 with Wi-Fi and Bluetooth
functions. Connection between AF20 and AG35 via the coexistence interface helps reduce the
interference between LTE signal and Wi-Fi/Bluetooth signal.
AF20 is an SMD type module with a compact form factor of 17.2 mm × 15.2 mm × 2.26 mm. It can be
embedded in your applications through the 52 LGA pins.
2.1. Key Features
Table 2: Key Features
Features
Implementation
Power Supply

VDD_3V3:
3.14 V–3.46 V
Typical value: 3.3 V

VDD_I/O:
1.71 V–1.89 V
Typical value: 1.8 V
Operating Frequency
 2.4 GHz Wi-Fi: 2.412 GHz–2.472 GHz
 5 GHz Wi-Fi: 5.180 GHz–5.825 GHz
 Bluetooth: 2.402 GHz–2.480 GHz
Wi-Fi Transmission Data
Rates
 802.11b: 1 Mbps, 2 Mbps, 5.5 Mbps, 11 Mbps
 802.11g: 6 Mbps, 9 Mbps, 12 Mbps, 18 Mbps, 24 Mbps, 36 Mbps, 48
Mbps, 54 Mbps
 802.11n (20 MHz): 6.5 Mbps, 13 Mbps, 19.5 Mbps, 26 Mbps, 39 Mbps,
52 Mbps, 58.5 Mbps, 65 Mbps
 802.11n (40 MHz): 13.5 Mbps, 27 Mbps, 40.5 Mbps, 54 Mbps, 81 Mbps,
