Quectel AF20 User Manual

Wi-Fi&Bluetooth Module Series
AF20_Hardware_Design
35
/ 49
4.4. RF Performances
Table 20: Conducted RF Output Power at 2.4 GHz
Frequency
Min.
Typ.
Unit
802.11b @ 1 Mbps
13.5
16
dBm
802.11b @ 11 Mbps
13.5
16
dBm
802.11g @ 6 Mbps
12.5
15
dBm
802.11g @ 54 Mbps
11.5
14
dBm
802.11n, HT20 @ MCS 0
12.5
15
dBm
802.11n, HT20 @ MCS 7
10.5
13
dBm
802.11n, HT40 @ MCS 0
12.5
15
dBm
802.11n, HT40 @ MCS 7
10.5
13
dBm
Table 21: Conducted RF Output Power at 5 GHz
Frequency
Min.
Typ.
Unit
802.11a @ 6 Mbps
9.5
12
dBm
802.11a @ 54 Mbps
8.5
11
dBm
802.11n, HT20 @ MCS 0
9.5
12
dBm
802.11n, HT20 @ MCS 7
6.5
9
dBm
802.11n, HT40 @ MCS 0
10
12.5
dBm
802.11n, HT40 @ MCS 7
5.5
8
dBm
802.11ac, VHT20 @ MCS 0
9.5
12
dBm
Tx VHT40 MCS 9 @ 8.1 dBm
214.2
5.9
mA
Tx VHT80 MCS 0 @ 10.7 dBm
329.1
5.9
mA
Tx VHT80 MCS 9 @ 7.1 dBm
192.1
5.9
mA
