802.11ac, VHT20 @ MCS 8
6.5
9
dBm
802.11ac, VHT40 @ MCS 0
10
12.5
dBm
802.11ac, VHT40 @ MCS 9
5.5
8
dBm
802.11ac, VHT80 @ MCS 0
8.5
11
dBm
802.11ac, VHT80 @ MCS 9
4.5
7
dBm
Table 22: Conducted RF Receiving Sensitivity at 2.4 GHz
Frequency
Receiving Sensitivity (Typ.)
802.11b, 1 Mbps
-95.0 dBm
802.11b, 11 Mbps
-88.0 dBm
802.11g, 6 Mbps
-90.0 dBm
802.11g, 54 Mbps
-73.5 dBm
802.11n, HT20, MCS 0
-89.5 dBm
802.11n, HT20, MCS 7
-70.5 dBm
802.11n, HT40, MCS 0
-87.5 dBm
802.11n, HT40, MCS 7
-68.5 dBm
Table 23: Conducted RF Receiving Sensitivity at 5 GHz
Frequency
Receiving Sensitivity (Typ.)
802.11a, 6 Mbps
-91.5 dBm
802.11a, 54 Mbps
-75.0 dBm
802.11n, HT20, MCS 0
-91.0 dBm
802.11n, HT20, MCS 7
-71.5 dBm
802.11n, HT40, MCS 0
-88.0 dBm
802.11n, HT40, MCS 7
-68.5 dBm
