Quectel BG95 Series Application Note

LPWA Module Series
BG95&BG77&BG600L Series TCP/IP Application Note
BG95&BG77&BG600L_Series_TCP/IP_Application_Note 8 / 56
1 Introduction
Quectel BG95 series, BG77 and BG600L-M3 modules feature an embedded TCP/IP stack, which
enables the host to access the Internet directly via AT commands. This greatly reduces the dependence
on external PPP and TCP/IP protocol stacks and thus minimizes the cost.
BG95 series, BG77 and BG600L-M3 modules provide the following socket services:
 TCP client
 UDP client
 TCP server
 UDP server
1.1. Applicable Modules
Table 1: Applicable Modules
Module Series
Model
Description
BG95
BG95-M1
Cat M1 only
BG95-M2
Cat M1/Cat NB2
BG95-M3
Cat M1/Cat NB2/EGPRS
BG95-M4
Cat M1/Cat NB2, 450 MHz Supported
BG95-M5
Cat M1/Cat NB2/EGPRS, Power Class 3
BG95-M6
Cat M1/Cat NB2, Power Class 3
BG95-MF
Cat M1/Cat NB2, Wi-Fi Positioning
BG77
BG77
Cat M1/Cat NB2
BG600L
BG600L-M3
Cat M1/Cat NB2/EGPRS

Quectel BG95 Series Specifications

General

Form Factor	LGA
Dimensions	23.6 mm × 19.9 mm × 2.2 mm
Operating Temperature	-40°C to +85°C
Storage Temperature	-45°C to +90°C
GNSS	GPS/GLONASS/BeiDou/Galileo/QZSS
SIM Interface	1.8V/3.0V
LTE-FDD Bands	B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B26/B28
LTE-TDD Bands	B39
Data rates LTE Cat NB2	Uplink: 127 kbps, Downlink: 158.5 kbps
Data rates EGPRS	Up to 296 kbps DL / 236.8 kbps UL
Protocols	TCP/UDP/HTTP/HTTPS/MQTT/LWM2M/CoAP
Interfaces	UART
Certifications	CE/FCC/PTCRB/IC/NCC/RCM/CCC
