General| Chipset | Qualcomm MDM9205 |
|---|---|
| LTE Category | Cat M1/Cat NB2 |
| GNSS | GPS/GLONASS/BeiDou/Galileo/QZSS |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -45°C to +90°C |
| SIM Interface | 1.8V/3V |
| Dimensions | 23.6 mm × 19.9 mm × 2.2 mm |
| LTE Cat NB2 Data Rate | 127kbps (DL), 158kbps (UL) |
| EGPRS Data Rate | 296kbps (DL), 236.8kbps (UL) |
| Supply Voltage Range | 3.3V to 4.3V |
| Power Consumption | PSM: 3.2 μA |
| Interfaces | UART, USB 2.0, I2C, SPI, GPIO, ADC |
| SMS | Text and PDU Mode |
| Protocols | TCP/UDP/PPP |
| Certifications | FCC, IC, CE, RCM, PTCRB, GCF |
| Frequency Bands | GSM: 850/900/1800/1900MHz |
