BG96 TCP/IP Application Note
BG96_TCP/IP_Application_Note 29 / 52
_data_format>,<recv_data_form
at>]
If the optional parameters are specified, set the format for the data
to be sent and received:
OK
If there is any error:
ERROR
Write Command
Query/set the output format of
received data (only for buffer
access mode and direct push
mode)
AT+QICFG="viewmode"[,<view_
mode>]
Response
If the optional parameter is omitted, query the current setting:
+QICFG: "viewmode",<view_mode>
OK
If the optional parameter is specified, set the output format of
received data:
OK
If there is any error:
ERROR
Write Command
Query/set the URC format of
TCP/IP buffer access mode. If this
command is set, when the module
receives data from a remote server,
the data length will be added to the
URC.
AT+QICFG="recvind",[<recv_ind
>]
Response
If the optional parameter is omitted, query the current setting:
+QICFG: "recvind",<recv_ind>
OK
If the optional parameter is specified, set the URC format of
TCP/IP buffer mode:
OK
If there is any error:
ERROR
Write Command
When module accesses to IPv4
address of a TCP/UDP server
under IPv6 network, the module will
translate IPv4 address to
IPv4-embedded IPv6 address
using the network-specific prefixes
or the well-known prefix.
AT+QICFG="prefix",[<IPv6_prefi
x>,<prefix_length>]
Response
If the optional parameters are omitted, query the current setting:
+QICFG: "prefix",<IPv6_prefix>,<prefix_length>
OK
If the optional parameters are specified, set the network-specific
prefixes or the well-known prefix:
OK
If there is any error:
ERROR
Write Command
Query/set the maximum interval
Response
If the optional parameters are omitted, query the current setting:

Quectel BG96 TCP/IP Specifications

General

Module Type	LTE Cat M1/Cat NB1/EGPRS
Form Factor	LGA
Frequencies GSM	850/900/1800/1900MHz
SIM Interface	1.8V/3V
Operating Temperature	-40°C to +85°C
Storage Temperature	-45°C to +90°C
Network Technology	LTE Cat M1, LTE Cat NB1, EGPRS
LTE Category	Cat M1/Cat NB1
Frequencies LTE FDD	B1/B3/B5/B8/B12/B13/B18/B19/B20/B26/B28
Frequencies LTE TDD	B39/B40/B41
LTE Max Data Rate (LTE Cat M1)	375 kbps
LTE Max Data Rate (LTE Cat NB1)	32 kbps (DL), 70 kbps (UL)
EGPRS Data Rate	296 kbps (DL), 236.8 kbps (UL)
Data Rate (LTE Cat M1)	375 kbps
Data Rate (LTE Cat NB1)	32Kbps (DL)/70Kbps (UL)
Interfaces	UART
GNSS	GPS, GLONASS, BeiDou, QZSS
Protocols	TCP/IP, UDP, HTTP, MQTT
Certifications	CE, FCC, IC, RCM
