Quectel BG96 - UART, USB, PCM, I2 C, and GPIO Interfaces

LPWA Module Series
BG96 Hardware Design
BG96_Hardware_Design 21 / 79
V
OL
max=0.45V
V
OH
min=2.55V
USIM_GND
47
Specified
ground for
(U)SIM card
UART1 Interface
Pin Name
Pin No.
I/O
Description
DC Characteristics
Comment
DTR
30
DI
Data terminal
ready (sleep
mode control)
V
IL
min=-0.3V
V
IL
max=0.6V
V
IH
min=1.2V
V
IH
max=2.0V
1.8V power domain.
If unused, keep this
pin open.
RXD
34
DI
Receive data
V
IL
min=-0.3V
V
IL
max=0.6V
V
IH
min=1.2V
V
IH
max=2.0V
1.8V power domain.
If unused, keep this
pin open.
TXD
35
DO
Transmit data
V
OL
max=0.45V
V
OH
min=1.35V
1.8V power domain.
If unused, keep this
pin open.
CTS
36
DO
Clear to send
V
OL
max=0.45V
V
OH
min=1.35V
1.8V power domain.
If unused, keep this
pin open.
RTS
37
DI
Request to
send
V
IL
min=-0.3V
V
IL
max=0.6V
V
IH
min=1.2V
V
IH
max=2.0V
1.8V power domain.
If unused, keep this
pin open.
DCD
38
DO
Data carrier
detection
V
OL
max=0.45V
V
OH
min=1.35V
1.8V power domain.
If unused, keep this
pin open.
RI
39
DO
Ring indication
V
OL
max=0.45V
V
OH
min=1.35V
1.8V power domain.
If unused, keep this
pin open.
UART2 Interface
Pin Name
Pin No.
I/O
Description
DC Characteristics
Comment
DBG_RXD
22
DI
Receive data
V
IL
min=-0.3V
V
IL
max=0.6V
V
IH
min=1.2V
V
IH
max=2.0V
1.8V power domain.
If unused, keep this
pin open.
DBG_TXD
23
DO
Transmit data
V
OL
max=0.45V
V
OH
min=1.35V
1.8V power domain.
If unused, keep this
pin open.
