It is recommended to reserve the above circuit design during application design.
3.16. ADC Interfaces
The module provides two analog-to-digital converter (ADC) interfaces. AT+QADC=0 command can be
used to read the voltage value on ADC0 pin. AT+QADC=1 command can be used to read the voltage
value on ADC1 pin. For more details about these AT commands, please refer to document [2].
In order to improve the accuracy of ADC voltage values, the trace of ADC should be surrounded by
ground.
Table 21: Pin Definition of ADC Interfaces
The following table describes the characteristics of ADC interfaces.
Table 22: Characteristics of ADC Interfaces
Pin Name
Pin No.
Description
ADC0
24
General purpose analog to digital converter interface
ADC1
2
General purpose analog to digital converter interface
Parameter
Min.
Typ.
Max.
Unit
ADC0 Voltage Range
0.3
1.8
V
ADC1 Voltage Range
0.3
1.8
V
ADC Resolution
15
bits
ADC Analog-input Bandwidth
100
kHz
ADC Sampling Rate
2.4
MHz
NOTE
