Table 17: EC25-A Mini PCIe Conducted RF Receiving Sensitivity
Table 18: EC25-J Mini PCIe Conducted RF Receiving Sensitivity
LTE-TDD bands
23dBm±2dB
<-44dBm
Frequency
Primary
Diversity
SIMO
3GPP (SIMO)
WCDMA B2
-110.0dBm
/
/
-104.7dBm
WCDMA B4
-110.0dBm
/
/
-106.7dBm
WCDMA B5
-110.5dBm
/
/
-104.7dBm
LTE FDD B2 (10M)
-98.0dBm
-98.0dBm
-101.0dBm
-94.3dBm
LTE FDD B4 (10M)
-97.5dBm
-99.0dBm
-101.0dBm
-96.3dBm
LTE FDD B12 (10M)
-96.5dBm
-98.0dBm
-101.0dBm
-93.3dBm
Frequency
Primary
Diversity
SIMO
3GPP (SIMO)
WCDMA B1
-110.0dBm
/
/
-106.7dBm
WCDMA B6
-110.5dBm
/
/
-106.7dBm
WCDMA B8
-110.5dBm
/
/
-106.7dBm
WCDMA B19
-110.5dBm
/
/
-106.7dBm
LTE-FDD B1 (10M)
-97.5dBm
-98.7dBm
-100.2dBm
-96.3dBm
LTE-FDD B3 (10M)
-96.5dBm
-97.1dBm
-100.5dBm
-93.3dBm
LTE-FDD B8 (10M)
-98.4dBm
-99.0dBm
-101.2dBm
-93.3dBm
LTE-FDD B18 (10M)
-99.5dBm
-99.0dBm
-101.7dBm
-96.3dBm
LTE-FDD B19 (10M)
-99.2dBm
-99.0dBm
-101.4dBm
-96.3dBm
LTE-FDD B26 (10M)
-99.5dBm
-99.0dBm
-101.5dBm
-93.8dBm
LTE-TDD B41 (10M)
-95.0dBm
-95.7dBm
-99.0dBm
-94.3dBm
