Quectel EG06 Series User Manual

LTE-A Module Series
EG06 Hardware Design
EG06_Hardware_Design 27 / 89
PCIE_TX_P
183
AO
PCIe transmission
- plus
If unused, keep it
open.
PCIE_RX_M
185
AI
PCIe receiving-
minus
If unused, keep it
open.
PCIE_RX_P
186
AI
PCIe receiving -
plus
If unused, keep it
open.
PCIE_CLK_
REQ_N
188
IO
PCIe clock request
V
OL
max=0.45V
V
OH
min=1.35V
V
IL
min=-0.3V
V
IL
max=0.6V
V
IH
min=1.2V
V
IH
max=2.0V
In master mode, it is
an input signal.
In slave mode, it is an
output signal.
If unused, keep it
open.
PCIE_RST_N
189
IO
PCIe reset
V
OL
max=0.45V
V
OH
min=1.35V
V
IL
min=-0.3V
V
IL
max=0.6V
V
IH
min=1.2V
V
IH
max=2.0V
In master mode, it is
an output signal.
In slave mode, it is an
input signal.
If unused, keep it
open.
PCIE_WAKE_
N
190
IO
PCIe wake
V
OL
max=0.45V
V
OH
min=1.35V
V
IL
min=-0.3V
V
IL
max=0.6V
V
IH
min=1.2V
V
IH
max=2.0V
V
IH
max=2.0V
In master mode, it is
an input signal.
In slave mode, it is an
output signal.
If unused, keep it
open.
WLAN Control Interface*
Pin Name
Pin No.
I/O
Description
DC Characteristics
Comment
PM_ENABLE
5
DO
Enable WLAN
power
V
OL
max=0.45V
V
OH
min=1.35V
1.8V power domain.
If unused, keep it
open.
WAKE_ON_
WIRELESS
160
DI
Wake up the host
(EG06 module) by
Wi-Fi module.
V
IL
min=-0.3V
V
IL
max=0.6V
V
IH
min=1.2V
V
IH
max=2.0V
1.8V power domain.
Active low.
If unused, keep it
open.
WLAN_EN
149
DO
WLAN function
enable control
V
OL
max=0.45V
V
OH
min=1.35V
1.8V power domain.
Active high.
If unused, keep it
open.
COEX_UART_
RX
146
DI
LTE/WLAN
coexistence signal
V
IL
min=-0.3V
V
IL
max=0.6V
V
IH
min=1.2V
V
IH
max=2.0V
1.8V power domain.
If unused, keep it
open.
