NB-loT Module Series
BC660K-GL-TE-B User Guide
BC660K-GL-TE-B_User_Guide 15 / 30
3.1.1. Interface Diagram of BC660K-GL-TE-B Used Alone
J301
J302
J303
J304
J206
Figure 4: Interface Diagram of BC660K-GL-TE-B Used Alone
3.1.2. Operation Procedures for Using a Single Board
1. Install a USB-UART driver, which can be downloaded from the following link:
https://www.ftdichip.com/Drivers/VCP.htm
