Quectel RG50-Q Series User Manual

5G/LTE-A Module Series
5G EVB User Guide
5G_EVB_User_Guide 9 / 38
2 General Overview
Quectel supplies 5G EVB for engineers to develop applications based on Quectel 5G and LTE-A
EG512R-EA modules. This EVB can be used to test basic functionalities of these modules.
2.1. Key Features
The following table describes the detailed features of 5G EVB.
Table 2: Key Features
Features
Implementation
Power Supply
DC power supply: 4.5–5.5 V
Typical: +5 V/ 3 A
Module TE-A Interface
Quectel 5G RG50xQ Series and LTE-A EG512R-EA modules supported
PHY TE-A Interface
PHY AR8035 supported
Wi-Fi TE-A Interface
Reserved
AP TE-A Interface
Reserved
SD Card Interface
SD card connector
(U)SIM Card Interface
Dual (U)SIM card supported: 1.8 V and 2.95 V
Audio Interfaces
⚫ 1 digital audio codec board interface:
Supporting ALC5616-TE-A and TLV320AIC3104-TE-A codec boards
⚫ 2 analog audio interfaces:
Used for loudspeaker and earphone
UART Interface
COM1 (J2002):
⚫ Main UART
⚫ For data communication
⚫ Default baud rate: 115200 bps
COM2 (J2003):
⚫ Debug UART
⚫ For debugging
