Quectel SG368Z-AP User Manual

Smart Module Series
SG368Z_Series_Hardware_Design 21 / 113
USB1_DM
83
AIO
USB1 2.0 differential
data (-)
USB1_SS_TX_P
84
AO
USB1 3.0 transmit
(+)
USB1_SS_TX_M
88
AO
USB1 3.0 transmit
(-)
USB1_SS_RX_P
89
AI
USB1 3.0 receive (+)
USB1_SS_RX_M
92
AI
USB1 3.0 receive (-)
USB2_DP
289
AIO
USB2 2.0 differential
data (+)
USB2_DM
292
AIO
USB2 2.0 differential
data (-)
USB3_DP
295
AIO
USB3 2.0 differential
data (+)
USB3_DM
297
AIO
USB3 2.0 differential
data (-)
PCIe Interfaces
Pin Name
Pin No.
I/O
Description
DC
Characteristics
Comment
PCIE1_TX_P
90
AO
PCIe1 transmit (+)
PCIE1_TX_M
91
AO
PCIe1 transmit (-)
PCIE1_RX_P
86
AI
PCIe1 receive (+)
PCIE1_RX_M
87
AI
PCIe1 receive (-)
PCIE1_REFCLK_P
81
AO
PCIe1 reference
clock (+)
PCIE1_REFCLK_M
82
AO
PCIe1 reference
clock (-)
PCIE1_CLKREQ_N
366
DI
PCIe1 clock request
VCCIO5
PCIE1_WAKE_N
367
DI
PCIe1 wake up
VCCIO5
PCIE1_RST_N
333
DO
PCIe1 reset
VCCIO5
PCIE2_TX0_P
58
AO
PCIe2 transmit 0 (+)
PCIE2_TX0_M
54
AO
PCIe2 transmit 0 (-)
PCIE2_TX1_P
63
AO
PCIe2 transmit 1 (+)
PCIE2_TX1_M
59
AO
PCIe2 transmit 1 (-)
