Quectel SG368Z-AP User Manual

Smart Module Series
SG368Z_Series_Hardware_Design 22 / 113
PCIE2_RX0_P
68
AI
PCIe2 receive 0 (+)
PCIE2_RX0_M
64
AI
PCIe2 receive 0 (-)
PCIE2_RX1_P
73
AI
PCIe2 receive 1 (+)
PCIE2_RX1_M
69
AI
PCIe2 receive 1 (-)
PCIE2_REFCLK_P
53
AI
PCIe2 reference
clock (+)
If unused, connect
this pin to ground.
PCIE2_REFCLK_M
49
AI
PCIe2 reference
clock (-)
If unused, connect
this pin to ground.
PCIE2_CLKREQ0_
N
364
DIO
PCIe2 channel 0
clock request
VCCIO5
When PCIe2 is
configured in PCIe
× 2 lane mode,
this pin is used for
clock request
function.
PCIE2_WAKE0_N
363
DIO
PCIe2 channel 0
wake up
VCCIO5
When PCIe2 is
configured in PCIe
× 2 lane mode,
this pin is used for
wake up function.
PCIE2_RST0_N
362
DIO
PCIe2 channel 0
reset
VCCIO5
When PCIe2 is
configured in PCIe
× 2 lane mode,
this pin is used for
reset function.
PCIE2_CLKREQ1_
N
368
DI
PCIe2 channel 1
clock request
VCCIO5
PCIE2_WAKE1_N
369
DI
PCIe2 channel 1
wake up
VCCIO5
PCIE2_RST1_N
358
DO
PCIe2 channel 1
reset
VCCIO5
SD Card Interface
Pin Name
Pin No.
I/O
Description
DC
Characteristics
Comment
SD_VDD
262
PO
SD card power
supply
Vnom = VBAT
Dedicated for SD
card power
supply.
SD_CLK
252
DO
SD card clock
VCCIO3
SD_CMD
247
DIO
SD card command
VCCIO3
SD_DATA0
246
DIO
SDIO data bit 0
VCCIO3
