Quectel SG368Z-AP User Manual

Smart Module Series
SG368Z_Series_Hardware_Design 25 / 113
HDMI Interface
Pin Name
Pin No.
I/O
Description
DC
Characteristics
Comment
HDMI_TX2_P
72
AO
HDMI data 2 (+)
HDMI_TX2_M
71
AO
HDMI data 2 (-)
HDMI_TX1_P
67
AO
HDMI data 1 (+)
HDMI_TX1_M
66
AO
HDMI data 1 (-)
HDMI_TX0_P
62
AO
HDMI data 0 (+)
HDMI_TX0_M
61
AO
HDMI data 0 (-)
HDMI_CLK_P
57
AO
HDMI clock (+)
HDMI_CLK_M
56
AO
HDMI clock (-)
HDMI_DET
379
DI
HDMI hot-plug
detect
V
IH
max = 5.3 V
V
IH
min = 2.4 V
Active high.
HDMI_SCL
387
OD
HDMI I2C clock
VCCIO7
HDMI_SDA
385
OD
HDMI I2C data
VCCIO7
HDMI_CEC
382
DIO
HDMI CEC signal
VCCIO7
Camera Interfaces
Pin Name
Pin No.
I/O
Description
DC
Characteristics
Comment
CSI_CLK0_N
2
AI
MIPI CSI clock 0 (-)
CSI_CLK0_P
3
AI
MIPI CSI clock 0 (+)
CSI_CLK1_N
6
AI
MIPI CSI clock 1 (-)
CSI_CLK1_P
9
AI
MIPI CSI clock 1 (+)
CSI_LN0_N
7
AI
MIPI CSI lane 0 data
(-)
CSI_LN0_P
8
AI
MIPI CSI lane 0 data
(+)
CSI_LN1_N
4
AI
MIPI CSI lane 1 data
(-)
CSI_LN1_P
5
AI
MIPI CSI lane 1 data
(+)
CSI_LN2_N
16
AI
MIPI CSI lane 2 data
(-)
