Quectel SG368Z-AP User Manual

Smart Module Series
SG368Z_Series_Hardware_Design 26 / 113
CSI_LN2_P
17
AI
MIPI CSI lane 2 data
(+)
CSI_LN3_N
11
AI
MIPI CSI lane 3 data
(-)
CSI_LN3_P
12
AI
MIPI CSI lane 3 data
(+)
CAM0_MCLK
279
DO
Master clock of
camera 0
VCCIO6
CAM0_RST
317
DO
Reset of camera 0
VCCIO6
CAM0_PWDN
316
DO
Power down of
camera 0
VCCIO6
CAM1_MCLK
75
DO
Master clock of
camera 1
PMUIO1
CAM1_RST
314
DO
Reset of camera 1
VCCIO6
CAM1_PWDN
313
DO
Power down of
camera 1
VCCIO6
RGMII Interfaces
Pin Name
Pin No.
I/O
Description
DC
Characteristics
Comment
RGMII0_RX0
183
DI
RGMII0 receive data
bit 0
VCCIO4
Only SG368Z-AP
supports this pin.
RGMII0_RX1
179
DI
RGMII0 receive data
bit 1
VCCIO4
RGMII0_RX2
174
DI
RGMII0 receive data
bit 2
VCCIO4
Only SG368Z-AP
supports this pin.
RGMII0_RX3
169
DI
RGMII0 receive data
bit 3
VCCIO4
Only SG368Z-AP
supports this pin.
RGMII0_RX_CTL
175
DI
RGMII0 receive
control
VCCIO4
RGMII0_RX_CLK
164
DI
RGMII0 receive
clock
VCCIO4
Only SG368Z-AP
supports this pin.
RGMII0_TX0
168
DO
RGMII0 transmit
data bit 0
VCCIO4
Only SG368Z-AP
supports this pin.
RGMII0_TX1
173
DO
RGMII0 transmit
data bit 1
VCCIO4
Only SG368Z-AP
supports this pin.
RGMII0_TX2
178
DO
RGMII0 transmit
data bit 2
VCCIO4
Only SG368Z-AP
supports this pin.
RGMII0_TX3
182
DO
RGMII0 transmit
data bit 3
VCCIO4
Only SG368Z-AP
supports this pin.
RGMII0_TX_CTL
172
DO
RGMII0 transmit
control
VCCIO4
Only SG368Z-AP
supports this pin.
