Quectel SG368Z Series User Manual

Smart Module Series
SG368Z_Series_Hardware_Design 18 / 113
2.5. Pins Description
Table 5: Parameters Definition
DC characteristics include power domain and rate current in the table below.
Table 6: Pins Description
Parameters
Descriptions
AI
Analog Input
AO
Analog Output
AIO
Analog Input/Output
DI
Digital Input
DO
Digital Output
DIO
Digital Input/Output
OD
Open Drain
PI
Power Input
PO
Power Output
Power Supply
Pin Name
Pin No.
I/O
Description
DC
Characteristics
Comment
VBAT
147, 148,
151, 152,
153, 156,
157, 161
PI
Power supply for the
module
Vmax = 3.5 V
Vmin = 3.3 V
Vnom = 3.4 V
VCCIO1
282
PO
1.8 V output power,
reference voltage for
VCCIO1 power
domain
Vnom = 1.8 V
VCCIO2
271
PO
1.8 V output power,
reference voltage for
VCCIO2 power
domain
Vnom = 1.8 V
