Quectel SG368Z Series User Manual

Smart Module Series
SG368Z_Series_Hardware_Design 80 / 113
4.15. GPIO
SG368Z-WF supports up to 107 GPIOs and SG368Z-AP supports up to 128 GPIOs. The reference
voltages of these GPIOs refer to the corresponding power domain. For the multiplexed GPIO, see
document [2].
Table 34: Pins Description of GPIO
RGMII1_RX0
296
56.84
RGMII1_RX1
294
56.26
RGMII1_RX2
308
56.87
RGMII1_RX3
307
57.30
RGMII1_RX_CTL
293
56.84
RGMII1_RX_CLK
304
56.02
RGMII1_TX0
305
43.33
RGMII1_TX1
303
43.90
RGMII1_TX2
312
42.52
RGMII1_TX3
310
42.21
RGMII1_TX_CTL
298
45.08
RGMII1_TX_CLK
306
43.29
Pin Name
Pin No.
I/O
Description
Comment
GPIO0_D3
125
DIO
General-purpose input/output
GPIO0_D4
60
DIO
General-purpose input/output
GPIO0_D5
80
DIO
General-purpose input/output
GPIO0_D6
10
DIO
General-purpose input/output
GPIO0_A5
123
DIO
General-purpose input/output
