SD_DATA1
251
DIO
SDIO data bit 1
VCCIO3
SD_DATA2
256
DIO
SDIO data bit 2
VCCIO3
SD_DATA3
257
DIO
SDIO data bit 3
VCCIO3
SD_DET
261
DI
SD card hot-plug
detect
PMUIO1
SD_PU_VDD
242
PO
1.8/3.3 V output
power for SD card
pull-up circuits
Vnom =
1.8/3.3 V
Touch Panel Interface
Pin Name
Pin No.
I/O
Description
DC
Characteristics
Comment
TP_RST
30
DO
TP reset
PMUIO2
TP_INT
35
DI
TP interrupt
PMUIO2
TP_I2C1_SCL
45
OD
TP I2C clock
PMUIO2
TP_I2C1_SDA
40
OD
TP I2C data
PMUIO2
LCM Interfaces
Pin Name
Pin No.
I/O
Description
DC
Characteristics
Comment
LCD1_RST
322
DO
LCD1 reset
VCCIO6
DSI0_CLK_N
37
AO
LCD0 MIPI clock (-)
DSI0_CLK_P
36
AO
LCD0 MIPI clock (+)
DSI0_LN0_N
47
AO
LCD0 MIPI lane 0
data (-)
DSI0_LN0_P
46
AO
LCD0 MIPI lane 0
data (+)
DSI0_LN1_N
42
AO
LCD0 MIPI lane 1
data (-)
DSI0_LN1_P
41
AO
LCD0 MIPI lane 1
data (+)
DSI0_LN2_N
32
AO
LCD0 MIPI lane 2
data (-)
DSI0_LN2_P
31
AO
LCD0 MIPI lane 2
data (+)
DSI0_LN3_N
27
AO
LCD0 MIPI lane 3
data (-)
