Smart Module Series
SG368Z_Series_Hardware_Design 77 / 113
Module
RGMIIx_TX0
RGMIIx_TX1
RGMIIx_TX2
RGMIIx_TX3
RGMIIx_TX_CTL
RGMIIx_TX_CLK
RGMIIx_RX0
RGMIIx_RX1
RGMIIx_RX2
RGMIIx_RX3
RGMIIx_RX_CTL
RGMIIx_RX_CLK
PHY_TX0
PHY_TX1
PHY_TX2
PHY_TX3
PHY_TX_CTL
PHY_TX_CLK
PHY_RX0
PHY_RX1
PHY_RX2
PHY_RX3
PHY_RX_CTL
PHY_RX_CLK
VCCIOx
VCCIO_PHY
R1
22R
R2
22R
R3
22R
R4
22R
R5
22R
R6
22R
R7
22R
R8
22R
R9
22R
R10
22R
R11
22R
R12
22R
RGMIIx_MDC
RGMIIx_MDIO
RGMIIx_MCLK
RGMII0_REFCLKOUT
R14
22R
PHY_MDC
PHY_MDIO
1.5K
CLK_OUT
R15
XTAL_IN
XTAL_OUT/EX_CLK
INT
PHYRST
GPIO
GPIO
PHY
R13
R16
(Option)
Figure 28: Reference Design of RGMII Interface PHY with External Crystal
