Quicksilver 855WE — System & Component Overview and Operaon
Dual Air Condioning
Water pickup
Seacock
Sea strainer
Water pump
Air condioner unit 16K
Air condioner unit 8K
Water outlet hose
Water outlet thru hull
Condensaon hose
Condensaon thru hull
Air duct
Forward berth grill
A berth grill
Salon grill
Return air vent
Control panel 16K
Control panel 8K
The 16,000 BTU air condioner provides air through three air ducts located throughout the boat. In the
forward berth, there is an adjustable air vent located on the port side next to the interior closet. In the
a berth, there is a vent located on the port side of the headliner, while in the salon, there is a vent
located on the port a pilaster. The 8,000 BTU air condioner has a single duct located on the port side
of the forward berth.
Maintenance
The following items should be inspected on a regular basis:
1. The seawater strainer located in the bilge should be cleaned out when necessary.
2. The sump pump should be cleaned out when necessary.
3. The air lter located on the air inlet on the air condioner should be removed and cleaned
periodically to make sure fresh, clean air is circulated throughout the boat.
