Overview of the screens
Digital input
screens
Designation Related topic
<d. in> Status of the digital inputs See section Digital inputs
<d. 1> Running hours See section Calling up running hours
<d. 2> Motor starts See section Calling up motor starts
<d. 3> Module hours See section Calling up module hours
<d. 4> Service timer reading See section Calling up/Resetting the service
timer
<d. 5 Actual program version
Parameter
screens
Designation Related topic
<P. 1> Selection between local, remote or LAN
control
See section Selection between Local
Remote and LAN control
<P. 2> Setting a node ID for LAN control and the
channels for Mk 4 and Mk 5
See section Calling up/modifying CAN
address control
<P. 3> Settings for IP, gateway and Subnet mask See section Calling up/modifying IP,
Gateway and Subnetmask
<P. 4> Service timer See section Calling up/modifying service
timer settings
<P. 5> Setting of the temperature unit See section Calling up/Modifying unit of
temperature
<P. 6> Setting of the pressure unit See section Calling up/Modifying unit of
pressure
<P. 7> Function: Automatic restart after voltage
failure
See section Activating automatic restart
<P. 8> Setting of dryer regulation mode See section Calling up/modifying dryer
regulation mode
<P. 9> Flow switch See section Calling up/modifying flow switch
function
<P. 10> Setting a password See section Activating password protection
<P. 11> Flexible or fixed alarm See section Selection between flexible
alarm and fixed alarm
<P. 12> Setting of fixed alarm See section Calling up/modification fixed
dew point alarm setting
<P. 13> Setting of flexible alarm See section Calling up/modification flexible
dew point alarm setting
Protections
screens
Designation Related topic
<Pr. 2> Low dew point alarm See section Shutdown warning
<Pr. 3> High ambient temperature alarm This value is fixed and cannot be modified.
See section Shutdown warning
Instruction book
2920 7103 90 21
