QED-350 up to QED-600 - dimension drawing
Reference Name
(1) Main supply electrical cable gland M25
(2) Manual drain
(3) Automatic drain
(4) Cooling air flow
(5) Air inlet
(6) Air outlet
Instruction book
2920 7103 90 39
