212 Rabbit 2000 Microprocessor
The MMIDR register shown in Table B-9 is used to enable and configure separate I & D
space support in addition to the /CS1 enable option used to improve the access time of
battery-backable SRAM.
NOTE: Bits [7:5] and [3:0] were always written with zero in the original Rabbit 2000 chip.
Table B-9. MMU Instruction/Data Register (MMIDR = 0x010)
MMU Instruction/Data Register (MMIDR) (Address = 0x10)
Bit(s) Value Description
7:6 00 These bits are ignored and always return zeros when read.
5
0 Enable A16 and A19 inversion independent of instruction/data.
1
Enable A16 and A19 inversion (controlled by bits 0-3) for data accesses only.
This enables the instruction/data split. This is separate I and D space.
4
0 Normal /CS1 operation.
1
Force /CS1 always active. This will not cause any conflicts as long as the
memory using /CS1 does not also share an Output Enable or Write Enable with
another memory.
3
0 Normal operation.
1 For a DATASEG access, invert A19 before MBxCR (bank select) decision.
2
0 Normal operation.
1 For a DATASEG access: invert A16
1
0 Normal operation.
1 For root access, invert A19 before MBxCR (bank select) decision.
0
0 Normal operation.
1 For root access, invert A16
