Warning: When you connect the test probes to LOGIC TEST
an AC outlet, do not tum the function selector The logic function lets you easily digital
switch to another range. It could damage the circuits to determine the logic state of different
meter’s intemal components or injure you. parts of the circuit. Rather than display an -
lute voltage, this function displays HI,LO, or ---
to indicate logic high, logic low, or undetermined,
respectively,
Follow these steps to perform a logic test.
1. Rotate the function selector to the HIGH/LOW
logic range.
31
