Radio Shack TRC-447 Service Manual

— 23 —
MECHANICAL PARTS LIST
Ref. No. Description RS Part No. Mfr’ s Part No.
1 Shield Case SPTE,T=0.3 HSDC453000Z
2 Shield Plate SPTE HSDC454315Z
3 Cushion NEOPRENE SP 25*15*15T RCUN435264Z
4 Holder: PCB SECC HHDZ4B5754Z
5 Panel, Front ABS GCAS2B5626Z
6 Display Window PC GCAS442091Z
7 Holder, Meter POLYETHY,MILK WHITE GHDM404812Z
8 Holder, LED ABS GHDZ442085Z
9 Knob ABS(PLATING),CR PLATING GNBZ442014Z
10 Knob ABS(PLATING),CR PLATING GNBZ442015Z
11 Cover, Bottom VINY TOP HCAS2B5627Z
12 Cover, Top VINY TOP HCAS2B5628Z
13 Front Piece HCAS3B5629Z
14 Chassis SPCC HCSY2B5630Z
15 Chassis SECC HCSY3B5631Z
16 Himelon RBLD4B6084Z
17 Blind Plate PVC 0.4T BLACK RETC412489Z
18 Wool-Coated Paper, Wool Tack WOOL PAPER,10*150*0.3T RUTC403865Z
19 Insulation Plate PVC,30*20*0.5T RZEB407154Z
20 Hardware Kit, Base HDWKT367ZHB
20-1 Screw, Flat HD + M3×4 NI SSCW133004N
20-2 Screw, Bind HD + M2.6×4 NI SSCW192604N
20-3 Screw, Bind HD + M3×5 NI SSCW193005N
20-4 Screw, Bind HD + M3×6 NI SSCW193006N
20-5 Screw, Bind HD + M3×8 NI SSCW193008N
20-6 Screw, Taptight Bind HD + M3×5 NI SSCW343005N
20-7 Screw, Taptight Bind HD + M3×6 NI SSCW343006N
20-8 Hex Nut M3.0 NI SSCW430030N
20-9 Nut, Flange M3 ZMC SSCW480030Z
20-10 Screw, Taptight Round HD + D3.5×8 NI SSCW293508N
20-11 Washer, Lock D3.5 NI SSCW530035N
20-12 Screw, Mounting ABS INST CLR BLACK GMSC405736A
20-13 Screw, Taptight Round HD + D5×10 NI SSCW295010N
20-14 Washer, Star D5 NI SSCW540050N
21 Spring Plate, Knob D6.02×L9.53 TSTD0200003
22 Cushion NEOPRENE RCUN4B6610Z
23 Hanger, Microphone SPCC,1.0T,NI HMHG402919Z
24 Mounting Bracket SPCC,1.6T,ZMC HBCT406058Z
25 Washer, Rubber EPT, BLACK 7×15×2.0T LWSR493891Z
26 Himelon RBLD451795Z
27 Cushion NEOPRENE RCUN451801Z
