— 38 —
Assembly, Switch PCB
Consists of the following:
Switch PCB ASSEMBLY
Ref. No. Description RS Part No. Mfr’s Part No.
B551 AT367ZHBB
Capacitors
Notes: All ceramic capacitors are Multilayer (1608) Tape type, unless otherwise specified.
The following codes indicate variations of capacitors against temperature:
B=±10%
Flat Cable
FC551 WF-353 3.5-70-3.5 8P BWFY3530700
FC552 WF-349 3.5-70-3.5 2P BWFY3490700
FC553 WF-351 3.5-70-3.5 5P BWFY3510700
Resistors
R550 Carbon Fixed Chip 10 kohm 1/16 W ±5 % BRFC161034Z
R552 Carbon Fixed Chip 10 kohm 1/16 W ±5 % BRFC161034Z
R556 Carbon Fixed Chip 0 ohm 1/16 W ±5 % BRFC160004Z
R561 Carbon Fixed Chip 1 kohm 1/16 W ±5 % BRFC161024Z
R562 Carbon Fixed Chip 10 kohm 1/16 W ±5 % BRFC161034Z
Switch
S551 Lever SW-841 BSWY0841001
S552 Lever SW-841 BSWY0841001
S555 Lever SW-841 BSWY0841001
S556 Lever SW-841 BSWY0841001
S557 Lever SW-838 BSWY0838001
To Next Page
